Description
Resources
Pinout
-
Connector Definition
| Type | Part Number | Part Name |
|---|
| Board Connector | SM06B-GHS-TB | JST-GH |
| Cable Connector | GHR-06V-S | JST-GH |
-
Connector Pinout
| Pin | Name | Description |
|---|
| 1 | VIN | Positive Voltage (+) |
| 2 | VIN | Positive Voltage (+) |
| 3 | VIN | Positive Voltage (+) |
| 4 | GND | Ground |
| 5 | GND | Ground |
| 6 | GND | Ground |
